Hydraulic Control Valves for Forklift

Forklift Hydraulic Control Valves - The function of directional control valves is to route the fluid to the desired actuator. Generally, these control valves comprise a spool positioned inside of a housing made either of cast iron or steel. The spool slides to various places in the housing. Intersecting grooves and channels direct the fluid based on the spool's position.

The spool is centrally situated, help in place with springs. In this particular position, the supply fluid can be blocked and returned to the tank. When the spool is slid to one direction, the hydraulic fluid is directed to an actuator and provides a return path from the actuator to tank. When the spool is moved to the other side, the return and supply paths are switched. When the spool is enabled to return to the neutral or center position, the actuator fluid paths become blocked, locking it into position.

Typically, directional control valves are designed so as to be stackable. They usually have one valve for each and every hydraulic cylinder and a fluid input that supplies all the valves within the stack.

Tolerances are maintained extremely tightly, to be able to tackle the higher pressures and in order to avoid leaking. The spools will normally have a clearance inside the housing no less than 25 Ã?â??Ã?µm or a thousandth of an inch. So as to avoid jamming the valve's extremely sensitive components and distorting the valve, the valve block would be mounted to the machine' frame by a 3-point pattern.

The location of the spool may be actuated by hydraulic pilot pressure, mechanical levers, or solenoids which push the spool left or right. A seal allows a part of the spool to protrude outside the housing where it is accessible to the actuator.

The main valve block is generally a stack of off the shelf directional control valves chosen by capacity and flow performance. Various valves are designed to be on-off, whereas others are designed to be proportional, as in valve position to flow rate proportional. The control valve is among the most sensitive and expensive parts of a hydraulic circuit.
